Water Well Rigs/KS Crawler Water Well Drilling Rigs
KS300A
The FY300-light is a lightweight crawler-mounted water well drilling rig with a maximum drilling depth of 300 m, hole diameter of 140-325 mm, powered by an 85 kW Yuchai engine, with a total weight of 6.8 t.
Dimensions & weight — Machine weight
6.8 t
Drilling capability — Drill pipe diameter
Φ76, Φ89 mm
Drilling capability — Hole diameter
140-325 mm
Drilling capability — Drill pipe length options
1.5/2.0/3.0 m
Overview
Product family: FY crawler series
The FY300-light is a lightweight crawler-mounted water well drilling rig with a maximum drilling depth of 300 m, hole diameter of 140-325 mm, powered by an 85 kW Yuchai engine, with a total weight of 6.8 t.
Key highlights
- ✓85 kW Yuchai engine delivering stable power with economical fuel consumption
- ✓Rig lifting force of 18 t plus a winch hoisting force of 2 t, a rapid rise speed of 22 m/min and a fast feed speed of 40 m/min for a penetration efficiency of 15-35 m/h
- ✓Refer to the published specification table for technical details.
- ✓Working air pressure of 1.7-3.0 MPa with an air consumption of 17-36 m³/min for efficient DTH drilling
- ✓Operating weight of 6.8 t, overall dimensions of 4100×2000×2260 mm and a climbing ability of 30° for flexible relocation.
Applications: agricultural irrigation, rural/urban water supply and geothermal drilling, combining 300 m depth capability with a lightweight design for easy relocation.
Specifications
Request the current specification sheet for this model using the button above.
Dimensions & weight
| Machine weight | 6.8 t |
Drilling capability
| Drill pipe diameter | Φ76, Φ89 mm |
| Hole diameter | 140-325 mm |
| Drill pipe length options | 1.5/2.0/3.0 m |
| Drilling depth | 300 m |
Other specifications
| Lifting capacity | 18 t |
| Feed stroke | 3.3 m |
| Rapid lifting speed | 22 m/min |
Performance & mobility
| Travel speed | 2.5 km/h |
Other specifications
| Rapid feed speed | 40 m/min |
Performance & mobility
| Maximum gradeability | 30° |
Dimensions & weight
| Loading width | 2.6 m |
Engine & drive
| Engine power | 85 kW |
| Engine manufacturer | Yuchai |
Other specifications
| Winch lifting capacity | 2 t |
| Working air pressure | 1.7-3.0 MPa |
| Rotary torque | 5700-7500 N·m |
| Air consumption | 17-36 m³/min |
Dimensions & weight
| Overall dimensions | 4100×2000×2260 mm |
Other specifications
| Rotary speed | 40-70 rpm |
Drilling capability
| Penetration rate | 15-35 m/h |
Other specifications
| Outrigger stroke | 1.4 m |
Applications
- Water well drilling
- Deep wells
- Geological drilling
Recommended packages
Air compressor match
KS300B-KS450 pair with the KSZJ-29/23 class (29 m³/min @ 2.3 MPa, 400 HP Yuchai) — the standard water-well pairing for 300-450 m programs.
DTH hammer & bits
Match hammers to the 140-350 mm hole range; each rig can ship as a complete package with DTH hammer and drill pipe sets.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KS300A?
Water well drilling, Deep wells, Geological drilling.
Which air compressor pairs with the KS300A?
KS300B-KS450 pair with the KSZJ-29/23 class (29 m³/min @ 2.3 MPa, 400 HP Yuchai) — the standard water-well pairing for 300-450 m programs.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
