Truck-Mounted Drilling Rigs/Mechanical Power Head Drilling Rigs
TEC-600J
The TEC-600J is a truck-mounted mechanical power head drilling rig on a two-axle engineering trailer, with a drilling depth of 600 m (750 m with 89 mm drill pipe), a hole diameter of 90–850 mm, a 60 t mast load at 9 m mast height, pull-down 10 t and pull-up 30 t, a power head with 28566–2500 N·m torque at 27–208 rpm, a Weichai 152 kW diesel engine, a BW1100/6 mud pump (1100 L/min at 6 MPa) and an operating weight of 16500 kg.
Drilling depth
600 m
Drilling depth with Ø89 mm drill pipe
750 m
Hole diameter
90–850 mm
Mast load capacity
60 t
Overview
The TEC-600J is a truck-mounted mechanical power head drilling rig on a two-axle engineering trailer, with a drilling depth of 600 m (750 m with 89 mm drill pipe), a hole diameter of 90–850 mm, a 60 t mast load at 9 m mast height, pull-down 10 t and pull-up 30 t, a power head with 28566–2500 N·m torque at 27–208 rpm, a Weichai 152 kW diesel engine, a BW1100/6 mud pump (1100 L/min at 6 MPa) and an operating weight of 16500 kg.
Key highlights
- ✓Drilling depth 600 m with 114 mm pipe and 750 m with 89 mm pipe.
- ✓60 t mast load at 9 m mast height, pull-down 10 t and pull-up 30 t.
- ✓Mechanical power head, 28566–2500 N·m torque at 27–208 rpm.
- ✓Weichai 152 kW diesel engine with a BW1100/6 mud pump (1100 L/min at 6 MPa).
- ✓Two-axle engineering trailer chassis for site transport.
Applications: Water wells to 600 m. · DTH hammer and mud drilling programs. · Trailer-mounted field work where a rigid truck chassis is not wanted.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Drilling depth | 600 m |
| Drilling depth with Ø89 mm drill pipe | 750 m |
| Hole diameter | 90–850 mm |
| Mast load capacity | 60 t |
| Mast height | 9 m |
| Pull-down force | 10 t |
| Pull-up force | 30 t |
| Power head torque | 28566–2500 N·m |
| Power head speed | 27–208 rpm |
| Engine | Weichai |
| Engine power | 152 kW |
| Mud pump | BW1100/6 |
| Mud pump flow | 1100 L/min |
| Mud pump pressure | 6 MPa |
| Chassis | Two-axle engineering trailer |
Dimensions & weight
| Overall dimensions | 10500 × 2500 × 4500 mm |
| Operating weight | 16500 kg |
Applications
- Water well drilling
- Deep boreholes
- Foundation drilling
Recommended packages
Air compressor match
Mechanical power head rigs drill with mud circulation (e.g. TEC-600J runs a BW1100/6 mud pump). Match the pump to depth and hole diameter rather than an air package.
DTH hammer & bits
Mud rotary method — drill pipes and bits match the power head torque (up to 29 000 N·m on TEC-J series). DTH conversion available on request.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the TEC-600J?
Water well drilling, Deep boreholes, Foundation drilling.
Which air compressor pairs with the TEC-600J?
Mechanical power head rigs drill with mud circulation (e.g. TEC-600J runs a BW1100/6 mud pump). Match the pump to depth and hole diameter rather than an air package.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
