Kaishan Surface Drilling Rigs/Compact Crawler DTH Drill Rig with Integrated Air Compressor Series
KZ9
KZ9 surface DTH drilling rig is an advanced drilling equipment which integrates the drilling system and the automatic pick-up and unloading rod system into one, with a compact structure and good integrality, which makes it easy to move. It is equipped with a sunshade canopy and side and rear reversing image, making the operation and movement of the rig safer and more comfortable. The movement of the drilling rig, including walking, advancing, rotating, dust collection and angle adjustment, is all driven hydraulically, providing strong climbing ability and stable performance. It is also equipped with a hydraulic dry dust collector to reduce pollution to the environment. The drilling rig is characterized by efficient drilling, energy conservation, safety, environment-friendliness, flexibility and simple operation. It also features a hydraulic rod unloading mechanism for disassembling the rods, and a rod handling device to reduce labour intensity. The drilling rig is mainly used for rock drilling work in quarrying projects and open-pit mines.
Model of drill rig
KZ9
Dimensions & weight — Weight
9300 kg
Dimensions & weight — Outer dimensions (L × W × H)
7550 x 2550 x 3100 mm
Drilling capability — Drilling hardness
f = 6-20
Overview
KZ9 surface DTH drilling rig is an advanced drilling equipment which integrates the drilling system and the automatic pick-up and unloading rod system into one, with a compact structure and good integrality, which makes it easy to move. It is equipped with a sunshade canopy and side and rear reversing image, making the operation and movement of the rig safer and more comfortable. The movement of the drilling rig, including walking, advancing, rotating, dust collection and angle adjustment, is all driven hydraulically, providing strong climbing ability and stable performance. It is also equipped with a hydraulic dry dust collector to reduce pollution to the environment. The drilling rig is characterized by efficient drilling, energy conservation, safety, environment-friendliness, flexibility and simple operation. It also features a hydraulic rod unloading mechanism for disassembling the rods, and a rod handling device to reduce labour intensity. The drilling rig is mainly used for rock drilling work in quarrying projects and open-pit mines.
Key highlights
- ✓Integrated DTH drilling system and automatic rod pick-up/unloading system in a compact, movable machine.
- ✓Sunshade canopy plus side and rear reversing image for safer, more comfortable operation and movement.
- ✓Walking, advancing, rotating, dust collection and angle adjustment are all hydraulically driven: strong climbing ability and stable performance.
- ✓Hydraulic dry dust collector reduces environmental pollution.
- ✓Hydraulic rod unloading mechanism and rod handling device reduce labour intensity.
- ✓Automatic oil injection lubrication for the drilling rod.
- ✓Mainly used for rock drilling in quarrying projects and open-pit mines.
Applications: Rock drilling in quarrying projects and open-pit mines. · Holes of φ115-165 mm at an economical drilling depth of 21 m, rock hardness f = 6-20. · Sites that pair the rig with a portable air compressor: the catalog recommends LGCY19/21-21/18, LGCY21/21-23/18 and LGCY23/23-25/18.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model of drill rig | KZ9 |
Dimensions & weight
| Weight | 9300 kg |
| Outer dimensions (L × W × H) | 7550 x 2550 x 3100 mm |
Drilling capability
| Drilling hardness | f = 6-20 |
| Drilling diameter | φ115-165 mm |
| Depth of economical drilling | 21 m |
| Revolving speed of gyrator | 0-80 (0-160) rpm |
| Rotary torque | 4000 N·m |
| Maximum feed force | 30000 N |
| Travelling speed | 0-3.0 km/h |
| Climbing capacity | ≤30° |
| Ground clearance | 330 mm |
| Power of complete machine | 86 kW |
| Diesel engine | Yuchai YC4DK115-T302 |
| Lifting angle of drill boom | up 50°, down 20° |
| Tilt angle of beam | 120° |
| Swing angle of carriage | left 47°, right 48° |
| Swing angle of drill boom | left 59°, right 48° |
| Leveling angle of frame | up 10°, down 10° |
| One-time advance length | 3500 mm |
| Compensation length | 900 mm |
Engine & drive
| DTH hammer | 4 in / 5 in |
| Drilling rod (φ × length) | φ76 (φ89) x 3000 mm |
| Storage capacity of rod | 7+1 |
| Dust collection method | Dry (hydraulic cyclonic laminar flow), 16 filter elements |
| Connecting rod method | Automatic unloading rod |
| Drill rod lubrication method | Automatic oil injection and lubrication |
Applications
- Small mines
- Quarrying
- Frequent-relocation sites
Recommended packages
Air compressor match
Integrated rig — the screw air compressor is built into the machine, so no separate compressor unit is needed. Only confirm the onboard compressor rating (pressure and flow) matches your hammer size.
DTH hammer & bits
Match the DTH hammer class to your hole diameter: K3/K30C for 90-105 mm, K5/K50 for 135-165 mm — see the DTH hammer series page for the full ladder.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KZ9?
Small mines, Quarrying, Frequent-relocation sites.
Which air compressor pairs with the KZ9?
Integrated rig — the screw air compressor is built into the machine, so no separate compressor unit is needed. Only confirm the onboard compressor rating (pressure and flow) matches your hammer size.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
