Kaishan Surface Drilling Rigs/Compact Crawler DTH Drill Rig with Integrated Air Compressor Series
ZT12
The ZT12 integrated surface DTH drilling rig can drill vertical, inclined and horizontal holes, and is mainly used for open-pit mines and stonework blast holes and pre-splitting holes. It is driven by a Cummins non-road diesel engine, and the screw compression system and hydraulic transmission system are simultaneously driven by the back-end flywheel and PTO port output. The drill rig is equipped with an automatic rod handling system, a drilling rod floating slide module, a drill pipe lubrication module, a drill pipe sticking prevention system, a hydraulic dry dust collection system and an air-conditioning cab, with optional drilling-angle and depth indication function. The drill rig is characterized by excellent integrity, high automation, efficient drilling, environment-friendliness, energy conservation, simple operation, flexibility and travelling safety.
Model of drill rig
ZT12
Dimensions & weight — Weight
16000 kg
Dimensions & weight — Transport dimensions (L × W × H)
10000 x 2480 x 3100 mm
Drilling capability — Rock hardness
f = 6-20
Overview
The ZT12 integrated surface DTH drilling rig can drill vertical, inclined and horizontal holes, and is mainly used for open-pit mines and stonework blast holes and pre-splitting holes. It is driven by a Cummins non-road diesel engine, and the screw compression system and hydraulic transmission system are simultaneously driven by the back-end flywheel and PTO port output. The drill rig is equipped with an automatic rod handling system, a drilling rod floating slide module, a drill pipe lubrication module, a drill pipe sticking prevention system, a hydraulic dry dust collection system and an air-conditioning cab, with optional drilling-angle and depth indication function. The drill rig is characterized by excellent integrity, high automation, efficient drilling, environment-friendliness, energy conservation, simple operation, flexibility and travelling safety.
Key highlights
- ✓Single Cummins diesel engine drives both the on-board screw compressor (rear flywheel output) and the hydraulic transmission (PTO output).
- ✓Automatic rod handling system, drilling rod floating slide module and drill pipe lubrication module.
- ✓Drill pipe sticking prevention system.
- ✓Hydraulic dry dust collection system.
- ✓Air-conditioned cab with optional drilling-angle and depth indication.
- ✓Can drill vertical, inclined and horizontal holes.
- ✓Excellent integrity, high automation, efficient drilling, environment-friendliness, energy conservation and travelling safety.
- ✓Drill rod thread automatic oil-spraying lubrication.
- ✓Mechanical floating protection for rod threads.
Applications: Open-pit mines and stonework, for blast holes and pre-splitting holes. · Vertical, inclined and horizontal holes of 115-152 mm at an economical drilling depth of 32 m. · Integrated rig: on-board two-stage screw compressor supplies 20 m³/min at 22 bar, so no separate air compressor is needed.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model of drill rig | ZT12 |
Dimensions & weight
| Weight | 16000 kg |
| Transport dimensions (L × W × H) | 10000 x 2480 x 3100 mm |
Drilling capability
| Rock hardness | f = 6-20 |
| Drilling diameter | 115-152 mm |
| Ground clearance | 430 mm |
| Leveling angle of track | ±10° |
| Travelling speed | 0-3 km/h |
| Climbing capacity | 25° |
| Traction | 87 kN |
| Rotary torque (max) | 4000 N·m |
| Rotation speed | 0-130 rpm |
| Swing angle of drill boom | left 17°, right 46° |
| Swing angle of the vertical of the carriage | left 52°, right 53° |
| Swing angle of the horizontal of the carriage | left 96°, right 30° |
| Tilt angle of beam | 147° |
| Compensation stroke | 1500 mm |
| Rotation head stroke | 4510 mm |
| Maximum propelling force | 39 kN |
| Method of propulsion | Motor + roller chain |
| Depth of economical drilling | 32 m |
Other specifications
| Number of rods | 6+1 |
| Specifications of drilling rod | Φ76/Φ89 x 4000 mm |
| DTH hammer | K5 |
| Engine | Cummins QSL8.9-C360-30 |
| Rated power | 264 kW |
| Rated revolving speed | 2100 r/min |
| Screw compressor | Two-stage compression 20 m³/min / 22 bar |
| Travelling control system | Hydraulic pilot |
| Drilling control system | Hydraulic pilot |
| Anti-jamming type | Electro-hydraulic anti-jamming |
| Voltage | 24V DC |
| Safe cab | ROPS & FOPS |
| Drill rod thread lubrication type | Automatic oil-spraying lubrication |
| Protection of rod threads | Mechanical floating protection |
| Air-conditioning | Standard cooling and heating |
| Entertainment | Radio |
Applications
- Small mines
- Quarrying
- Frequent-relocation sites
Recommended packages
Air compressor match
Integrated rig — the screw air compressor is built into the machine, so no separate compressor unit is needed. Only confirm the onboard compressor rating (pressure and flow) matches your hammer size.
DTH hammer & bits
Match the DTH hammer class to your hole diameter: K3/K30C for 90-105 mm, K5/K50 for 135-165 mm — see the DTH hammer series page for the full ladder.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the ZT12?
Small mines, Quarrying, Frequent-relocation sites.
Which air compressor pairs with the ZT12?
Integrated rig — the screw air compressor is built into the machine, so no separate compressor unit is needed. Only confirm the onboard compressor rating (pressure and flow) matches your hammer size.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
