Kaishan Surface Drilling Rigs/Photovoltaic Pile Drilling Rig Series
KG200GF
KG200GF is a Photovoltaic Pile Drilling Rig. Published specifications include working pressure 1-2.4 MPa; air consumption 15-26 m³/min; drive power Yuchai DKC2G3 (73.5 kW/2200 r/min); hole diameter φ115-203 mm; weight 5500 kg. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Hole diameter
φ115-203 mm
Weight
5500 kg
Overview
KG200GF is a Photovoltaic Pile Drilling Rig. Published specifications include working pressure 1-2.4 MPa; air consumption 15-26 m³/min; drive power Yuchai DKC2G3 (73.5 kW/2200 r/min); hole diameter φ115-203 mm; weight 5500 kg. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Genuine Kaishan equipment supplied through our authorized distribution channel, with configuration, export coordination, spare-parts and after-sales support.
Specifications
Request the current specification sheet for this model using the button above.
Drilling capability
| Rock hardness | F=6-20 |
| Hole diameter (mm) | φ115-203 |
| Feed length (mm) | 3475 |
Dimensions & weight
| Weight (kg) | 5500 |
| Dimensions (mm) | 6250×2260×2600 |
Drive & handling
| Rotary speed | 0-110 rpm |
| Max rotary torque | ≥3500 N·m |
| Lifting force | 40 kN |
| Track leveling angle | ±10° |
| Mast compensation length (mm) | 900 |
Tooling & air
| DTH hammer | 4-6" |
| Drill rod | φ76×2000 mm |
| Air consumption | 15-26 m³/min |
Performance & mobility
| Travel speed | 0-2.5 km/h |
| Gradeability | ≤30° |
| Ground clearance (mm) | 325 |
Applications
- Photovoltaic pile foundations
- Solar farm construction
- Hydropower & construction
Recommended packages
Air compressor match
Match a KSCY mobile air compressor to the hammer size and your hole plan — send us the hole diameter, depth and rock conditions and we confirm the exact pairing before quotation.
DTH hammer & bits
Match the DTH hammer class to your hole diameter (K3/K30C for 90-105 mm, K5/K50 for 135-165 mm, K8/K80 for 195-254 mm) — see the DTH hammer series page.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KG200GF?
Photovoltaic pile foundations, Solar farm construction, Hydropower & construction.
Which air compressor pairs with the KG200GF?
Match a KSCY mobile air compressor to the hammer size and your hole plan — send us the hole diameter, depth and rock conditions and we confirm the exact pairing before quotation.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
