Kaishan Air Compressors/Crawler-mounted Mining Air Compressor Series
DLGF1.2/8-7.5B
DLGF1.2/8-7.5B is an electric-motor screw air compressor from Kaishan's BMVF mining-safety series. It delivers 1.2 m³/min at a discharge pressure of 0.8 MPa with a 7.5 kW motor and weighs 170 kg.
Model
DLGF1.2/8-7.5B
Tooling & air — Discharge pressure
0.8 MPa
Tooling & air — Air delivery
1.2 m³/min
Tooling & air — Motor power
7.5 kW
Overview
DLGF1.2/8-7.5B is an electric-motor screw air compressor from Kaishan's BMVF mining-safety series. It delivers 1.2 m³/min at a discharge pressure of 0.8 MPa with a 7.5 kW motor and weighs 170 kg.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model | DLGF1.2/8-7.5B |
Tooling & air
| Discharge pressure | 0.8 MPa |
| Air delivery | 1.2 m³/min |
| Motor power | 7.5 kW |
| Discharge port | G¾ |
Dimensions & weight
| Weight | 170 kg |
| Overall dimensions (L × W × H) | 880 x 510 x 800 mm |
Applications
- Mining operations
- Tunnel engineering
- Emergency rescue & mobile site air supply
Recommended packages
What this unit powers
Match a KSCY mobile air compressor to the hammer size and your hole plan — send us the hole diameter, depth and rock conditions and we confirm the exact pairing before quotation.
Pressure & flow matching rules
Match the DTH hammer class to your hole diameter (K3/K30C for 90-105 mm, K5/K50 for 135-165 mm, K8/K80 for 195-254 mm) — see the DTH hammer series page.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the DLGF1.2/8-7.5B?
Mining operations, Tunnel engineering, Emergency rescue & mobile site air supply.
What drilling equipment does the DLGF1.2/8-7.5B power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
