Kaishan Air Compressors/Crawler-mounted Mining Air Compressor Series
MLGF24/8-160T
MLGF24/8-160T is a MLGF Mining Compressor Unit. Published specifications include discharge pressure 0.8 MPa; air delivery 24.0 m³/min; electric motor 132 kW; outlet G2x1,G3/4x1; weight 3150 kg; dimensions 3065x1835x2000 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Working pressure
0.8 MPa
Air delivery
24.0 m³/min
Engine
132 kW
Weight
3150 kg
Overview
MLGF24/8-160T is a MLGF Mining Compressor Unit. Published specifications include discharge pressure 0.8 MPa; air delivery 24.0 m³/min; electric motor 132 kW; outlet G2x1,G3/4x1; weight 3150 kg; dimensions 3065x1835x2000 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Genuine Kaishan equipment supplied through our authorized distribution channel, with configuration, export coordination, spare-parts and after-sales support.
Specifications
Request the current specification sheet for this model using the button above.
Performance & capacity
| Discharge pressure (MPa) | 0.8 |
| Air delivery (m³/min) | 24.0 |
Engine & drive
| Motor power | 132 kW |
Dimensions & weight
| Weight (kg) | 3150 |
| Dimensions (mm) | 3065x1835x2000 |
Other specifications
| Air outlet | G2x1,G3/4x1 |
Applications
- Mining operations
- Tunnel engineering
- Emergency rescue & mobile site air supply
Recommended packages
What this unit powers
Match a KSCY mobile air compressor to the hammer size and your hole plan — send us the hole diameter, depth and rock conditions and we confirm the exact pairing before quotation.
Pressure & flow matching rules
Match the DTH hammer class to your hole diameter (K3/K30C for 90-105 mm, K5/K50 for 135-165 mm, K8/K80 for 195-254 mm) — see the DTH hammer series page.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the MLGF24/8-160T?
Mining operations, Tunnel engineering, Emergency rescue & mobile site air supply.
What drilling equipment does the MLGF24/8-160T power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
