Kaishan Air Compressors/Crawler-mounted Mining Air Compressor Series
MLGF27/25-315T
MLGF27/25-315T is an electric-motor screw air compressor from Kaishan's mobile mining series. It delivers 27.0 m³/min at a discharge pressure of 2.5 MPa with a 280 kW motor and weighs 5850 kg.
Model
MLGF27/25-315T
Tooling & air — Discharge pressure
2.5 MPa
Tooling & air — Air delivery
27.0 m³/min
Tooling & air — Motor power
280 kW
Overview
MLGF27/25-315T is an electric-motor screw air compressor from Kaishan's mobile mining series. It delivers 27.0 m³/min at a discharge pressure of 2.5 MPa with a 280 kW motor and weighs 5850 kg.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model | MLGF27/25-315T |
Tooling & air
| Discharge pressure | 2.5 MPa |
| Air delivery | 27.0 m³/min |
| Motor power | 280 kW |
| Discharge port | G2 x 1, G¾ x 1 |
Dimensions & weight
| Weight | 5850 kg |
| Overall dimensions (L × W × H) | 4115 x 1950 x 2440 mm |
Applications
- Mining operations
- Tunnel engineering
- Emergency rescue & mobile site air supply
Recommended packages
What this unit powers
Match a KSCY mobile air compressor to the hammer size and your hole plan — send us the hole diameter, depth and rock conditions and we confirm the exact pairing before quotation.
Pressure & flow matching rules
Match the DTH hammer class to your hole diameter (K3/K30C for 90-105 mm, K5/K50 for 135-165 mm, K8/K80 for 195-254 mm) — see the DTH hammer series page.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the MLGF27/25-315T?
Mining operations, Tunnel engineering, Emergency rescue & mobile site air supply.
What drilling equipment does the MLGF27/25-315T power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
