Kaishan Air Compressors/High-pressure Deep Well Air Compressor Series
LGZJ-36/30-41/20K
LGZJ-36/30-41/20K is a diesel-driven screw air compressor. Its brochure specification lists discharge pressure of 3.0-2.0 MPa, air delivery of 36-41 m³/min, a Cummins 550 HP engine, and weight of 5800 kg. The water-well compressor series combines electronic operating supervision, cooling and multi-stage filtration for demanding drilling-site conditions. Remote network monitoring is optional.
Model
LGZJ-36/30-41/20K
Tooling & air — Discharge pressure
3.0-2.0 MPa
Tooling & air — Air delivery
36-41 m³/min
Tooling & air — Supporting engine
Cummins 550 HP
Overview
LGZJ-36/30-41/20K is a diesel-driven screw air compressor. Its brochure specification lists discharge pressure of 3.0-2.0 MPa, air delivery of 36-41 m³/min, a Cummins 550 HP engine, and weight of 5800 kg. The water-well compressor series combines electronic operating supervision, cooling and multi-stage filtration for demanding drilling-site conditions. Remote network monitoring is optional.
Key highlights
- ✓SKY screw air end with a proprietary rotor profile and heavy-duty bearing design, as described for the water-well compressor series.
- ✓Electronic operating display covers engine speed, air pressure, engine oil pressure, discharge temperature, coolant temperature and fuel level.
- ✓Self-diagnosis, fault alarms and protective shutdown support operating supervision.
- ✓Separate oil, water and air coolers with a large-diameter fan provide thermal management for varying ambient conditions.
- ✓Multi-stage intake filtration combines centrifugal pre-cleaning, a main filter and a safety element for dusty operating environments.
- ✓Oil-air separation and lubricating-oil filtration protect the compressor air circuit and moving components; fuel filtration protects the engine injection system.
- ✓Remote network monitoring is available as an option; it is not assumed to be fitted to every machine.
Applications: Compressed-air supply for water-well drilling, matched to the required drilling air pressure and delivery.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model | LGZJ-36/30-41/20K |
Tooling & air
| Discharge pressure | 3.0-2.0 MPa |
| Air delivery | 36-41 m³/min |
| Supporting engine | Cummins 550 HP |
| Discharge port | G2 x 1, G¾ x 1 |
Dimensions & weight
| Weight | 5800 kg |
| Overall dimensions (L × W × H) | 3800 x 2160 x 2330 mm |
Applications
- Water well drilling
- Deep well drilling
- Geothermal drilling
Recommended packages
What this unit powers
Deep wells need high pressure: 2.5-3.5 MPa for KS800/KS1000 class rigs and geothermal projects. Dual-mode switching covers rigs at different depths.
Pressure & flow matching rules
Match high-pressure hammers for 800-1000 m programs; confirm hammer pressure rating against the unit before ordering.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the LGZJ-36/30-41/20K?
Water well drilling, Deep well drilling, Geothermal drilling.
What drilling equipment does the LGZJ-36/30-41/20K power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
