Kaishan Air Compressors/High-pressure Deep Well Air Compressor Series
LGZJ-30/35-35/25
LGZJ-30/35-35/25 is a High-Pressure Diesel Air Compressor. Published specifications include discharge pressure 3.5-2.5 MPa; air delivery 30-35 m³/min; engine power Yuchai 560HP; weight 6000 kg; dimensions 3800x2160x2300 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Working pressure
3.5-2.5 MPa
Air delivery
30-35 m³/min
Engine
Yuchai 560 HP
Weight
6000 kg
Overview
LGZJ-30/35-35/25 is a High-Pressure Diesel Air Compressor. Published specifications include discharge pressure 3.5-2.5 MPa; air delivery 30-35 m³/min; engine power Yuchai 560HP; weight 6000 kg; dimensions 3800x2160x2300 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Genuine Kaishan equipment supplied through our authorized distribution channel, with configuration, export coordination, spare-parts and after-sales support.
Specifications
Request the current specification sheet for this model using the button above.
Performance & capacity
| Discharge pressure (MPa) | 3.5-2.5 |
| Air delivery (m³/min) | 30-35 |
Engine & drive
| Engine power | Yuchai 560 HP |
Dimensions & weight
| Weight (kg) | 6000 |
| Dimensions (mm) | 3800x2160x2300 |
Other specifications
| Air outlet | G2x1,G³/4x1 |
Applications
- Water well drilling
- Deep well drilling
- Geothermal drilling
Recommended packages
What this unit powers
Deep wells need high pressure: 2.5-3.5 MPa for KS800/KS1000 class rigs and geothermal projects. Dual-mode switching covers rigs at different depths.
Pressure & flow matching rules
Match high-pressure hammers for 800-1000 m programs; confirm hammer pressure rating against the unit before ordering.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the LGZJ-30/35-35/25?
Water well drilling, Deep well drilling, Geothermal drilling.
What drilling equipment does the LGZJ-30/35-35/25 power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
