Kaishan Air Compressors/Electric Drive Mobile Air Compressor Series
KSDY-33.5/20
KSDY-33.5/20 is a KSDY Electric Drive Compressor Unit. Published specifications include discharge pressure 2.0 MPa; air delivery 33.5 m³/min; electric motor 280 kW; outlet G2x1,G³/4x1; weight 5800 kg; dimensions 3750x1950x2440 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Working pressure
2.0 MPa
Air delivery
33.5 m³/min
Engine
280 kW
Weight
5800 kg
Overview
KSDY-33.5/20 is a KSDY Electric Drive Compressor Unit. Published specifications include discharge pressure 2.0 MPa; air delivery 33.5 m³/min; electric motor 280 kW; outlet G2x1,G³/4x1; weight 5800 kg; dimensions 3750x1950x2440 mm. Use the model specification table to compare the selected equipment with project conditions and confirm the final configuration before order.
Genuine Kaishan equipment supplied through our authorized distribution channel, with configuration, export coordination, spare-parts and after-sales support.
Specifications
Request the current specification sheet for this model using the button above.
Performance & capacity
| Discharge pressure (MPa) | 2.0 |
| Air delivery (m³/min) | 33.5 |
Engine & drive
| Motor power | 280 kW |
Dimensions & weight
| Weight (kg) | 5800 |
| Dimensions (mm) | 3750x1950x2440 |
Other specifications
| Air outlet | G2x1,G³/4x1 |
Applications
- Mobile drilling support
- Construction sites
- Remote work areas
Recommended packages
What this unit powers
Electric site air: confirm three-phase supply capacity and motor voltage before ordering — KSDY covers 10-40 m³/min @ 0.8-2.5 MPa.
Pressure & flow matching rules
For DTH support, match flow to hammer consumption plus margin; PMDY variable-frequency models adapt delivery to changing air demand.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KSDY-33.5/20?
Mobile drilling support, Construction sites, Remote work areas.
What drilling equipment does the KSDY-33.5/20 power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
