Kaishan Air Compressors/Electric Drive Mobile Air Compressor Series
KSDY15/17
The KSDY series is an electric-driven mobile screw air compressor with rated discharge pressure of 1.7 MPa and air delivery of 15.0 m³/min, driven by a 132 kW (2-pole) electric motor, with a total weight of 2975 kg.
Working pressure
1.7 MPa
Air delivery
15.0 m³/min
Weight
2975 kg
Overview
The KSDY series is an electric-driven mobile screw air compressor with rated discharge pressure of 1.7 MPa and air delivery of 15.0 m³/min, driven by a 132 kW (2-pole) electric motor, with a total weight of 2975 kg.
Key highlights
- ✓Rated discharge pressure 1.7 MPa with air delivery 15.0 m³/min
- ✓132 kW (2-pole) electric motor with low running cost, zero exhaust emission and low noise
- ✓SKY patented screw air end with Kaishan's proprietary rotor profile for high efficiency
- ✓Total weight 2975 kg and dimensions of 3065x1835x2000 mm in a mobile structure for easy on-site layout
- ✓Intelligent electronic control and high-efficiency cooling system for stable operation and easy maintenance
Applications: Mining, tunneling, hydropower stations, factories and other sites with power supply, working with DTH drilling rigs, sandblasting equipment, pipeline pressure testing and other air-consuming devices.
Genuine Kaishan equipment supplied through our authorized distribution channel, with configuration, export coordination, spare-parts and after-sales support.
Specifications
Request the current specification sheet for this model using the button above.
Performance & capacity
| Discharge pressure (MPa) | 1.7 |
| Air delivery (m³/min) | 15.0 |
Dimensions & weight
| Weight (kg) | 2975 |
| Dimensions (mm) | 3065x1835x2000 |
Other specifications
| Air outlet | G2x1,G³/4x1 |
Applications
- Mobile drilling support
- Construction sites
- Remote work areas
Recommended packages
What this unit powers
Electric site air: confirm three-phase supply capacity and motor voltage before ordering — KSDY covers 10-40 m³/min @ 0.8-2.5 MPa.
Pressure & flow matching rules
For DTH support, match flow to hammer consumption plus margin; PMDY variable-frequency models adapt delivery to changing air demand.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KSDY15/17?
Mobile drilling support, Construction sites, Remote work areas.
What drilling equipment does the KSDY15/17 power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
