Kaishan Air Compressors/Single-stage Diesel Mobile Air Compressor Series
KSCY-215/19-G2
KSCY-215/19-G2 is a diesel-engine portable screw air compressor from Kaishan's KSCY series. It delivers 18.5 m³/min at a discharge pressure of 1.9 MPa, driven by a 215 HP Cummins engine, and weighs 2732 kg.
Model
KSCY-215/19-G2
Tooling & air — Discharge pressure
1.9 MPa
Tooling & air — Air delivery
18.5 m³/min
Tooling & air — Supporting engine
Cummins 215 HP
Overview
KSCY-215/19-G2 is a diesel-engine portable screw air compressor from Kaishan's KSCY series. It delivers 18.5 m³/min at a discharge pressure of 1.9 MPa, driven by a 215 HP Cummins engine, and weighs 2732 kg.
Key highlights
- ✓Automatic air-volume control: according to working pressure, the air-volume control device steplessly adjusts intake volume and engine speed so that air supply and air demand match, reaching the best result at the lowest fuel consumption.
- ✓Low-noise operation: silent-type canopy design keeps running noise low and makes the machine more environmentally friendly.
- ✓Purpose-built engine: Yuchai and Cummins heavy-duty engines keep the machine in its optimal combustion range across the whole operating envelope, giving higher reliability, stronger power and better fuel economy.
- ✓SKY patented rotor profile: a dedicated rotor tooth profile for each model gives superior performance, with an innovative design and optimised structure for higher reliability.
- ✓Rational design lowers operating cost: compact overall structure, light and easy to move on site, saving site-moving time.
- ✓Openable design for easy maintenance: wide-opening access doors place the air filter, oil filter and oil-gas separator within reach, and parts needing service are at hand, cutting downtime and maintenance time.
Applications: Air supply for down-the-hole drilling rigs and other pneumatic site equipment requiring 18.5 m³/min at 1.9 MPa; the catalog notes the final compressor choice depends on hole diameter and air-hose length.
Specifications
Request the current specification sheet for this model using the button above.
Other specifications
| Model | KSCY-215/19-G2 |
Tooling & air
| Discharge pressure | 1.9 MPa |
| Air delivery | 18.5 m³/min |
| Supporting engine | Cummins 215 HP |
| Discharge port | G2 x 1, G¾ x 1 |
Dimensions & weight
| Weight | 2732 kg |
| Overall dimensions (L × W × H) | 3200 x 1520 x 2405 mm |
Applications
- Mobile compressed-air supply
Recommended packages
What this unit powers
KSCY is itself the drilling-air source — match it to the rig's air demand: KG420B 10-17 m³/min, KG520 15-22 m³/min. One KSCY can feed several rigs on a fleet.
Pressure & flow matching rules
Pressure must cover the hammer rating (2.0-2.3 MPa covers most 3"-4" hammers) and flow the hammer consumption plus 10-15% margin.
Need a complete drilling package? Request a rig + compressor + tooling quote →
Frequently asked questions
What applications suit the KSCY-215/19-G2?
Mobile compressed-air supply.
What drilling equipment does the KSCY-215/19-G2 power?
This compressor supplies drilling air to DTH rigs and hammers — match the discharge pressure to the hammer rating and the air delivery to the hammer consumption plus 10-15% margin. Tell us your rig model and hammer size and we will confirm the pairing.
Can the equipment be configured to my project?
Send your project details through the inquiry form and we will confirm the available configuration for the selected model before quotation.
